Yoder Grills – Loaded Wichita Offset Wood Pit – YD-A41676

The Loaded Wichita offset smoker takes our three most popular options and makes them standard features: cooking door counterweight, heat management plate & 2nd level slide-out shelf. Pitmasters have plenty of room to work as this format boasts over 1600 square inches of total cooking surface. Handcrafted with precision, the Wichitas dual-damper draft control system helps manage that perfect balance of heat and thin blue smoke, making a quick pitmaster out of backyard cooks and taking seasoned pitmasters to the next level.

STANDARD FEATURES

• American Made in Kansas, USA
• Door Counterweight
• Stay Cool Handles
• Dual Door Temperature Gauges
• Integrated Probe Port
• Grease Drain
• Pot Warmer
• Offset Firebox
• 2nd Level Slide-Out Shelf
• Heat Management Plate
• Log Grate
• Wagon Wheels
• Expanded Metal Front Shelves
• Ash Cleanout Tool

SPECIFICATIONS

Cooking Surface:1610 Sq. Inches

• Two 19.8×19 Cooking Grates
• 35.5×14.5 2nd Level Slide-Out Cooking Shelf
• 19×18 Cooking Grate in Firebox

Cooking Chamber Thickness – Inch SteelOverall Length – 77.9Overall Height – 58.2Overall Depth -34.5 (Including Front Shelf)Weight – 591 lbs
IMPORTANT DOCUMENTSDimensional DrawingUser ManualFAQ
DISCLAIMER

Please note product images, specs and other information provided may change at any time without notice and may not reflect the units in stock at dealer location. We pride ourselves on working with companies who are constantly researching and developing better products and as such specs may change with little or no notice.
