UNI-T Single Function Temperature Calibrator | UT701

The UNI-T UT701 Single Function Temperature Calibrator is a high-precision tool designed for the calibration and maintenance of temperature sensors in industrial environments. It supports 10 types of thermocouples and 4 types of RTDs, allowing versatile applications. The device features easy-to-operate keys, selectable step and ramp outputs, and a 6-digit display for clear readings. With an output accuracy of up to 0.05%, the UT701 ensures reliable calibration results. Its robust design includes an LCD backlight, auto power-off function, and a drop-proof bi-color injection case, making it suitable for field use.

Specifications & Features:

• Output Accuracy: Up to 0.05%
• Display: 6-digit
• Output Functions: DC voltage, resistance, thermocouple, RTD
• Thermocouple Support: J, K, T, E, R, S, B, N, Wre325, Wre526
• RTD Support: Pt10, Pt100, Cu50, Cu100
• Ramp Functions: Slow ramp, fast ramp, 25% step-ramp
• Power: 9V battery
• Weight: 410g
• Size: 96mm x 193mm x 47mm
• Accessories: Test leads, battery, cloth bag
• Durability: 1m drop proof
