UNI-T 5kV Insulation Resistance Tester + USB (01.0T) | UT513A

The UNI-T UT513A Insulation Resistance Tester is designed for accurate testing of insulation resistance in large transformers, generators, and high-voltage motors. This tester equipped with a large 9999 display and a 30-segment analog bar graph for easy data visualization. This tester support PI/DAR measurements and feature test voltages up to 5kV. With data storage capabilities, USB connectivity for PC analysis, and safety features like high-voltage output alarms, this device ensure reliable and efficient performance in demanding environments.

Specifications & Features:

• Display: 9999 count with analog bar graph
• Insulation resistance ():
  • Test voltages:
    • 500V: 0.5M~20G
    • 1000V: 1M~40G
    • 2500V: 2.5M~100G
    • 5000V: 5M~1000G
• DC voltage (V): 600V
• AC voltage (V): 600V
• Short-circuit current: >3mA
• Data Storage: 18 groups
• Safety Features: Auto current discharge, high-voltage output alarm, auto power off
• Power: 1.5V batteries (LR14) x 8
• net weight: 2kg
• Product size: 202mm x 155mm x 94mm
