UNI-T 1kV Insulation Resistance Tester (010G) | UT511

The UNI-T UT511Insulation Resistance Tester is designed for accurate testing of insulation resistance in large transformers, generators, and high-voltage motors. This tester equipped with a large 9999 display and a 30-segment analog bar graph for easy data visualization. This tester support PI/DAR measurements and feature test voltages up to 1kV. with safety features like high-voltage output alarms, this device ensure reliable and efficient performance in demanding environments.

Specifications & Features:

• Display: 9999 count with analog bar graph
• Insulation resistance ():
  • Test voltages:
    • 100V: 0.1M~500M
    • 250V: 0.5M~2G
    • 500V: 1M~4G
    • 1000V: 2M~10G
• DC voltage (V): 1000V
• AC voltage (V): 750V
• Short-circuit current: <2mA
• Low resistance (): 0.1~999.9
• Data Storage: 18 groups
• Safety Features: Auto current discharge, high-voltage output alarm, auto power off
• Power: 1.5V batteries (LR14) x 8
• net weight: 1.2kg
• Product size: 202mm x 155mm x 94mm
