NGK BKR6EIX-11/03 3764 Iridium IX Spark Plug

The NGK BKR6EIX-11 3764 Iridium IX Spark Plug is engineered to provide exceptional ignition performance for various automotive applications. Featuring a fine wire 0.6 mm iridium tip, this spark plug ensures superior ignitability and a consistently stable spark. The iridium alloy center electrode offers six times the hardness of platinum, making it highly durable and capable of withstanding extreme conditions.

This spark plug’s design includes a tapered ground electrode that reduces quenching, resulting in better combustion and improved throttle response. The solid copper core and high-grade alumina silicate ceramic insulator provide excellent heat dissipation and dielectric strength. The trivalent metal plating delivers superior anti-corrosion and anti-seizing properties, ensuring easy installation and removal.

Specifications & Features:

• Model Number: BKR6EIX-11
• Part Number: 3764
• Electrode Material: Iridium center electrode, copper core
• Heat Range: 6
• Resistor: Yes, 5000 Ohm
• Thread Size: 14mm x 1.25
• Reach: 19mm
• Hex Size: 5/8 inch (16mm)
• Gap Size: 0.044 inch (1.1mm)
• Seat Type: Gasket
• Ground Electrode Tip Design: Tapered
• Insulator Height: 50.5mm

Compatible with:
