DP2C Wire-free Peephole Doorbell

Enjoy visible security anytime and anywhere.
A two-in-one peephole camera and doorbell, the DP2C features a sleek modern design, as well as multiple advanced features to stand guard at your front door. Youll enjoy its clear imaging, smart functions, and the power to see and talk to visitors via the indoor color monitor. Also, use the EZVIZ App on your mobile device and get alerts for any suspicious activity around your doorstep.

Features:

• 1080p Video
• 155 Ultra-wide-angle View
• PIR Motion Detection
• Live View & Two-way Video Call
• 4.3-inch Color Screen
• Night Vision Up to 5 m (16 ft)
• Built-in Electronic Doorbell
• 4600mAh Rechargeable Lithium Battery
• H.265 Video Technology
• Supports MicroSD Card (up to 256 GB)

Upgrade your door viewer with 1080p video quality
The DP2C captures all front-door activities in FHD resolution, and allows real-time video viewing from both the EZVIZ App and the indoor color screen. The large, 4.3-inch screen is especially useful for the elderly and children, helping them to see whos outside more easily and clearly.

• 4.3-inch Color Screen

It rings and lets you know whos knocking.
When the visitor presses the doorbell button, you hear a pleasant ringtone thanks to the DP2Cs built-in chime, and receive a real-time video call on your phone. This way, youll know how to respond even before you get the door.

Smarter detection with real-time alerts.
Do you get worried about your home while youre away? The DP2C ensures you get mobile alerts about any front-door visitors right away, thanks to its PIR motion detection feature.
Whether you live in an apartment with a narrow hallway, or a house with a large front yard, you can always customize your alert trigger conditions by selecting one of three levels of detection sensitivity.

Brilliant vision to reduce blind spots, even in dim light.
The DP2C provides optimal visual coverage with its 155-degree ultra-wide-angle lens, and renders sharp night vision of objects up to 5 meters away. It is also smart enough to automatically shift between day and night modes.

Sturdy and stylish design.
Thoughtfully designed, the DP2C fits seamlessly onto your door with easy installation. The exterior camera features an anti-prying design so its fully tamperproof, protecting your familys privacy.

Compatible Door Thickness:
35 – 105mm
16.5 – 50mm

Compatible Peephole Diameter:
Long-lasting protection with 3-month battery life*.

Equipped with a built-in 4,600 mAh rechargeable lithium battery, the DP2C ditches any complex wiring. The extended standby time reaches up to 90 days* with its smart power-saving functionality.

*Data from EZVIZs strict lab results, based on the usage of 5 minutes per day under standard conditions.

We protect your data and privacy.
Protecting your data and privacy is our highest priority. Data transmission between the device and the EZVIZ Cloud is encrypted from end to end. Only you have the keys to decrypt your data.

• AES 128-bit encryption
• TLS encryption protocol
• Multi-step authentication

Specifications

Model: CS-DP2C
Installation Parameters
Supported Hole Diameter: 16.5 to 50 mm (0.65 to 1.97 inch)
Supported Door Diameter: 35 to 105 mm (1.38 to 4.13 inch)

Camera Parameters
Sensor: 1/3″ Progressive Scan CMOS
Lens: 2.0 mm @ F2.2, visual angle (diagonal):155
Day/Night Switch: ICR infrared filter
IR Distance: Max. 5m
Max. Resolution: 1080p / 2MP
Video Frame Rate: 15fps
PIR Detection
Angle: 110
Distance: Max. 6m (20 ft)
Sensitivity: Adjustable

Interface
Storage Interface: MicroSD card slot (max. 256 GB)
Audio Input: Built-in high sensitivity microphone
Audio Output: Built-in high-power speaker
Buttons: Doorbell button, power button, Screen wake up button

Network
Face Detection: Does not support
Intelligence Alarm: PIR motion detection
Protocol: EZVIZ Cloud Proprietary Protocol
Video Intercom: Local and remote video intercom
General Function: Cloud video encryption and image encryption

Wireless
Wi-Fi Standard: IEEE802.11b, 802.11g, 802.11n
Frequency Range: 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth: Supports 20 MHz
Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmission Rate: 11b: 11Mbps, 11g :54Mbps, 11n :150Mbps

General
Screen: 4.3-inch color screen
Color: Silver
Operating Conditions: -10C to 45C (14F to 113 F ), Humidity 95% or less (non-condensing)
Power Supply: DC 5V (10%)
Power Consumption: Max. 2.2W
Dimension: Screen and Base: 115.5 x 85.5 x 24.5 mm (4.55 x 3.37 x 0.96 inch)
Peephole Doorbell: 71 x 71 x 48.3 mm (2.80 x 2.80 x 1.90 inch)
Weight: 302 g (10.65 oz)

In the box
In the box: – DP2C Peephole Doorbell
– Panel
– Mounting Base
– Power Cable (1 m / 3.3 ft)
– Screws 6
– Quick Start Guide

Certifications
Certifications: UL / FCC / CE / WEEE / REACH / RoHS
